Digital time switch 230VAC SELEKTA 172 top3
Source photo:
THEBEN
(fig. might be different or similar)

Digital time switch 230VAC SELEKTA 172 top3

EAN/GTIN: 4003468170175
WEEE: DE 48221059
Manufacturer: THEBEN
Manufacturer no.: SELEKTA 172 top3
Manufact.-SKU: 1720130
Customs tariff no.: 91070000
Similar top items: Show now & compare
173,53 GBP Price incl. VAT (0,00 GBP)
plus shipping
Delivery time:
3-5 days [GB] Central warehouse item (regularly available) - live request to the central warehouse directly in the cart or click the link below the price >Quantity available?<
pce

We always deliver the latest available article version.
Minimum order value (UK): 150 EUR (Sub total)

Note:
The installation of electrical devices may only be carried out by an approved electrician and, in the case of high-voltage systems (> = 400V and country-specific nominal power), only with the consent of the respective electricity network operator.

Details

Accessory
bought
Useful
Interesting

Digital time switch 230VAC Mounting method DIN rail, Number of channels 2, Supply voltage 230 ... 230V, Voltage type of supply voltage AC, Frequency supply voltage 50 ... 60Hz, Autonomy in years 10, Accuracy per day 0,25s, Text guidance in display, External programming, 60 min. program, 24 h program, Weekly program, Holiday program, Astro program, Hour meter, Quartz controlled, Contact type Change-over contact, Shortest switching time channel 1 1min, Number of memory locations 84, Automatic switching summer-/winter time, Manual operation, External pushbutton input, Switching preselection, Nominal switching current at 250 V AC 16A, Potential free switch contact, Degree of protection (IP) IP20, Width in number of modular spacings 2, Width 35mm, Height 128mm, Depth 35mm

More product images:

Product image Theben SELEKTA 172 top3 Digital time switch 230VAC
Product image
Dimensional drawing Theben SELEKTA 172 top3 Digital time switch 230VAC
Dimensional drawing
