Earth leakage circuit breaker PXK-B25/1N/003-A
Source photo:
Eaton
(fig. might be different or similar)

Earth leakage circuit breaker PXK-B25/1N/003-A

EAN/GTIN: 4015082369507
WEEE: DE 92318050
Manufacturer: Eaton
Manufacturer no.: PXK-B25/1N/003-A
Manufact.-SKU: 236950
Customs tariff no.: 85362010
Similar top items: Show now & compare
158,53 EUR Price incl. tax. 19,00%
plus shipping
Delivery time:
11 days [EN] Items to be procured that can be ordered (no central warehouse item) - live request to the central warehouse directly in the cart or click the link below the price >Quantity available?<
pce

We always deliver the latest available article version.

Note:
The installation of electrical devices may only be carried out by an approved electrician and, in the case of high-voltage systems (> = 400V and country-specific nominal power), only with the consent of the respective electricity network operator.

Details

Accessory
bought
Useful
Interesting

Number of poles (total)=2, Number of protected poles=1, Rated voltage=240 V, Rated insulation voltage Ui=440 V, Rated impulse withstand voltage Uimp=4 kV, Rated current=25 A, Rated fault current=0,02999999 A, Leakage current type=A, Current limiting class=3, Rated short-circuit breaking capacity according to EN 61009=10 kA, Rated short-circuit breaking capacity according to IEC 60947-2=0 kA, Rated short-circuit breaking capacity Icn according to EN 61009-1=10 kA, Surge current capacity=0,25 kA, Voltage type=AC, Frequency=50 Hz, Release characteristic=B, Concurrently switching neutral conductor=yes, With interlocking device=no, Over voltage category=3, Pollution degree=2, Ambient temperature during operating=-25..40 °C, Width in number of modular spacings=2, Built-in depth=69,5 mm, Flush-mounted installation=no, Anti-nuisance tripping version=no, Degree of protection (IP)=IP20, Connectable conductor cross section solid-core=1..25 mm², Connectable conductor cross section multi-wired=1..25 mm²

More product images:

Product image Eaton PXK B25 1N 003 A Earth leakage circuit breaker
Product image
View left Eaton PXK B25 1N 003 A Earth leakage circuit breaker
View left
Front view Eaton PXK B25 1N 003 A Earth leakage circuit breaker
Front view
View right Eaton PXK B25 1N 003 A Earth leakage circuit breaker
View right
